| 项目/形式 |
CRH-100T/E |
CRH-200T/E |
CRH-400T/E |
CRH-750T/E |
CRH-1500T/E |
| Power
source |
Tree phase
200V 50/60Hz 220V 60Hz |
| Output kW |
0.2 |
0.2 |
0.4 |
0.75 |
1.5 |
| Frequency Hz |
50/60/60 |
50/60/60 |
50/60/60 |
50/60/60 |
50/60/60 |
| Current A |
1.2/1.1/1.0(T)
1.1/1.0/1.0(E) |
1.2/1.1/1.0(T)
1.1/1.0/1.0(E) |
2.0/1.8/1.7 |
3.3/3.1/2.8(T)
3.1/3.0/2.8(E) |
6.2/5.8/5.4(T)
5.7/5.7/5.2(E) |
| Max
air flow m3/min |
2.1/2.4 |
2.7/3.2 |
4.7/5.8 |
8.0/9.6 |
14/17 |
| Max
static pressure暗 kPa |
0.30/0.42 |
0.50/0.73 |
0.80/1.10 |
1.00/1.40 |
1.60/2.20 |
| Noise
in field 1m dB∈A∷ |
56/60 |
59/63 |
62/66 |
67/71 |
70/72 |
| Collection
efficiency ◇ |
99.4∈Gravimetric
method oil mist∷ |
| Highest
intake temperature ☆ |
80 |
| Mass
kg |
13 |
20 |
24 |
32 |
49 |
| Inlet
diameter mm |
φ98 |
φ98 |
φ98 |
φ123 |
φ148 |
| Ambient
temperature ☆ |
MAX.40 |
| Color |
Main body N-8(white),
side cover etc 2.5PB 3.5/108(blue), mount NH(black) |
| Standard
accessories |
| primary filter
(for replacement)...1 sheet
drain tubes 2.5mm...2?unit
Hose bands (for drain tubes)...2 unit |
unitvibration
absorption pads...4 unit
tooling paper template...1 sheet
companion flange set...1?unit |
|
|
